Thank you for shopping at MaruyamaParts.com and for using the parts lookup system to find parts for your MP2530CE-1. You have selected the Main Body diagram for the Maruyama MP2530CE-1 Water Pumps. Below you will find an interactive part diagram for the MP2530CE-1 Main Body. If you find the part in the diagram you need you may click on the item number in the diagram or find it in the parts list below the diagram. For the MP2530CE-1 parts not shown in this diagram you may select from one of the other MP2530CE-1 part assemblies or select a different Water Pumps altogether. Thanks for shopping with us at MaruyamaParts.com and for making us your source for Maruyama Water Pumps parts.
 |
| Position number | SKU | Product title | Price | |
|---|---|---|---|---|
| 2 | 092513 | 092513 - BOLT |
$2.99
|
|
| 3 | 283896 | 283896 - CASING COVER |
$28.99
|
|
| 4 | 240002 | 240002 - MECHANICAL SEAL |
$24.99
|
|
| 5 | 550162 | 550162 - NLA SCREW |
$2.99
|
|
| 6 | 013918 | 013918 - O-RING |
$2.99
|
|
| 7 | 283910 | 283910 - IMPELLER |
$14.99
|
|
| 8 | 284812 | 284812 - GASKET |
$2.99
|
|
| 10 | 283911 | 283911 - PROTECTOR |
$20.99
|
|
| 11 | 027533 | 027533 - O-RING |
$2.99
|
|
| 12 | 283897 | 283897 - CASING |
$42.99
|
|
| 13 | 012615 | 012615 - O-RING |
$6.99
|
|
| 14 | 092520 | 092520 - BOLT |
$2.99
|
|
| 15 | 240553 | 240553 - USE: 240719 |
$16.99
|
|
| 16 | 283914 | 283914 - CHECK VALVE |
$7.99
|
|
| 17 | 092519 | 092519 - BOLT |
$2.99
|
|
| 18 | 283916 | 283916 - COVER |
$5.99
|
|
| 19 | 284422 | 284422 - O-RING |
$2.99
|
|
| 20 | 283907 | 283907 - BASE |
$46.99
|
|
| 23 | 549288 | 549288 - NLA HOSE |
No Longer Available Obsolete. |
|
| 24 | 284300 | 284300 - STRAINER |
$19.99
|
|
| 25 | 549653 | 549653 - BOX SPANNER |
$2.99
|
|
| 26 | 240028 | 240028 - USE: 272283 |
$5.99
|
|
| 27 | 240858 | 240858 - HOSE COUPLING |
$5.99
|
|
| 28 | 240859 | 240859 - PACKING |
$2.99
|
|
| 29 | 284301 | 284301 - HOSE BAND |
$2.99
|
|
| 30 | 240860 | 240860 - HOSE COUPLING |
$2.99
|
|
| 31 | 240861 | 240861 - NLA ADAPTER |
$2.99
|
|
| 32 | 284562 | 284562 - ONE TOUCH COUPLING |
$39.99
|
